Features :
PCIe 4.0 NVMe Technology
Master intensive applications with speeds up to 7,000/7,000MB/s1 read/write.
Greater flexibility
Compact M.2 design fits easily into small-form-factor (SFF) systems, desktops and laptop PCs.
Low profile graphene aluminum heat spreader
Exceptional thermal dissipation keeps your drive cool with maximum performance.
Specification :
| Form Factor | M.2 2280 |
| Interface | PCIe 4.0 NVMe |
| Capacities | 2048GB |
| Controller | Phison E18 |
| NAND | 3D TLC |
| Sequential read/write | 7,000/7,000MB/s |
| Random 4K read/write1 | up to 1,000,000/1,000,000 IOPS |
| Total Bytes Written (TBW)3 | 1.6PBW |
| Power consumption | 5mW idle / 0.36W avg / 2.8W (MAX) read / 9.9W (MAX) write |
| Storage temperature | -40°C~85°C |
| Operating temperature | 0°C~70°C |
| Dimensions | 80mm x 22mm x 3.5mm |
| Weight | 9.7g |
| Vibration operating | 2.17G peak (7-800Hz) |
| Vibration non-operating | 20G Peak (20-1000Hz) |
| MTBF | 1,800,000 hours |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
