Features

Think Big. Build Small.

O11D MINI adding to the O11 Dynamic series, the classic and mordern looking. A case that would accommodate the maximum number of water-cooling configurations without being oversized. With a modular back panel design, the user has the option to choose from 3 slots/ 5 slots/ 7 slots I/O shield to optimize the case to the configuration of user’s choice. Supports mini-ITX, micro-ATX, ATX, motherboard sizes. and up to 9 fans to cool the chassis.

Key Features

Space for ATX-, Micro-ATX- or Mini-ITX-form factor
motherboards
A wide range of configuration options for radiators and fans at
the top, bottom, and beside the motherboard
three different pump stands are provided to accommodate
different water cooling scenarios.
Can hold up to 4 storage drives
Support 2 x USB 3.0, 1 x USB 3.1 TYPE-C. 1 x HD Audio

Specifications

Product Name	O11 Dynamic MINI
MODEL	O11D Mini-X
COLOR	Black
DIMENSIONS	(D)420mm X (W)269.5mm X (H)380mm
MOTHERBOARD	ATX/ Micro-ATX/ Mini-ITX
PSU	SFX/ SFX-L
MATERIAL	0.8mm SPCC (body) 1mm SPCC (interior, back panel) 4 mm Tempered Glass 2mm Aluminum (top and left panel)
FAN SUPPORT	Top: 3x 120mm or 2x 140mm Side: 2x 120mm or 2x 140mm Bottom: 3x 120mm or 2x 140mm Rear: 1x 120mm
RADIATOR SUPPORT	Top: 360mm or 280mm or 240mm radiator Side: 240mm or 280mm radiator Bottom: 360 or 280mm or 240mm radiator
GPU LENGTH CLEARANCE	395mm
CPU COOLER HEIGHT CLEARANCE	170mm
VGA Length	370mm
DRIVES	Right side 2 x 2.5″ SSD + back plate 2 x 3.5″ HDD (or SSD)
EXPANSION SLOTS	3 or 5 or 7 slots (depends on back panel)
IO PORTS	2 x USB 3.0, 1 x USB 3.1 TYPE-C, 1 x HD Audio, Power Button
DUST FILTERS	1 x Top, 1 x Bottom, 2 x Side
Warranty	1 Year
Note	***Features, Price and Specifications are subject to change without notice.

SKU	: G99-O11DMI-X-IN
BRAND	: Lian Li
