MAG CORELIQUID M360 Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.The unique curved copper plate is designed to fully cover the CPU while offering rapid heat dissipation.
Features:
Elevated Copper Plate
The unique curved copper plate is designed to fully cover the CPU while offering rapid heat dissipation.
Pump Motor Resonance Elimination
A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.
HIGH THERMAL DISSIPATION
The radiator has a 12 pathway designed to help rapidly dissipate heat.
EVAPORATION PROOF TUBING
Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.
EXTENSIVE COMPATIBILITY
Stylish yet built for flexibility, the MAG CORELIQUID M360 has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.
Intel Socket
LGA 1150/1151/1155/1156/1200/1700
LGA 2011/2011-3/2066
AMD Socket
AM5/AM4/TR4
Specifications:
| Â Product Name | MAG CORELIQUID M360 |
| Â Radiator Dimensions (WxDxH) | 397 x 120 x 27 mm / 15.63 x 4.7 x 1.06 inches |
| Â Number of Fans | Â 3 |
| Â Fan Dimensions | 120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches |
| Â Fan Power Consumption | 4.2 W |
| Â Fan Rated Current | 0.35 A |
| Â Fan Life Expectancy | 70,000 hours |
| Â Fan Bearing | Two Ball Bearing |
| Â Fan Air Flow | 21.63 ~ 78.73 CFM |
| Â Fan Lighting | Â ARGB |
| Â PWM Mode | Â YES |
| Â Radiator Material | Â Aluminum |
| Â Block Dimensions | 67.26 x 59.95 x 55.9 mm |
| Fan Cable Length (5V ARGB / PWM cable) | 350 mm / 13.78 inches |
| Â Pump Rated Current | Â 0.38 A |
| Â Pump Life Expectancy | Â 100,000 Hours |
| Â Pump Noise Level | Â 20 dBA |
| Â Pump Connector | Â 3 Pin |
|  Pump Speed |  3100 RPM ± 10% |
| Â Pump Power Consumption | Â 4.56W |
| Â Intel Socket | Â LGA 1150/1151/1155/1156/1200/1700 LGA 2011/2011-3/2066 |
| Â AMD Socket | Â AM5/AM4 |
| Â Radiator Size | Â 360 mm |
| Â Cold Plate Material | Â Copper + Plastic |
| Â Warranty | Â 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
