Features
Unify your power and join the dark side. Win games and set records with 12+2+1 IR digital power, All-Metal Extended Heatsink, Triple Lightning M.2 with Shield Frozr, Audio Boost HD, Game Boost and 2.5G Gaming LAN plus WIFI 6 solution.
- Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for AM4 socket
- Supports DDR4 Memory, up to 4600+(OC) MHz
- Aluminum Cover with Extended Heatsink: All-metal extended heatsink cover enlarge the surface of heat dissipation, ensures even high-end processors to run in full speed.
- Lightning Fast Game Experience: PCIe 4.0, Triple Lightning Gen4 x4Â M.2 with M.2 Shield Frozr, StoreMI, AMD Turbo USB 3.2Â Gen2.
- 2.5G Gaming LAN with Latest Wi-Fi 6 Solution: Onboard 2.5G LAN with gaming LAN manager, combining latest Wi-Fi 6 solution which supports MU-MIMO and BSS color technology, delivering the best online gaming experience.
- Frozr Heatsink Design:Â Â Designed with the patented fan and double ball bearings to provide the best performance for enthusiast gamers and prosumers.
- Audio Boost HD: Isolated audio with dedicated processor combining ESS audio DAC with amplifier, deliver the breathtaking, game-changing sound to create the most exciting gameplay.
- Pre-installed I/O Shielding: Better EMI protection and more convenience for installation
Specifications
Processor |
Supports 2nd and 3rd Gen AMD Ryzenâ„¢ / Ryzenâ„¢ with Radeonâ„¢ Vega Graphics and 2nd Gen AMD Ryzenâ„¢ with Radeonâ„¢ Graphics Desktop Processors for Socket AM4 |
Chipset |
AMD X570 Chipset |
Memory |
- 4x DDR4 memory slots, support up to 128GB
- 3rd Gen AMD Ryzenâ„¢ Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400 /4533 /4600 Mhz by A-XMP OC MODE
- 2nd Gen AMD Ryzenâ„¢ Processors, 1st and 2nd Gen AMD Ryzenâ„¢ with Radeonâ„¢ Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667 /2800 / 2933 /3000 /3066 /3200 /3466 /3600 Mhz by A-XMP OC MODE
- Dual channel memory architecture
- Supports non-ECC UDIMM memory
- Supports ECC UDIMM memory (non-ECC mode)
- Supports un-buffered memory
|
Slots |
- 2x PCIe 4.0/ 3.0 x16 slots (PCI_E1, PCI_E3)
- 3rd Gen AMD Ryzenâ„¢ support PCIe 4.0 x16/x0, x8/x8 modes
- 2nd Gen AMD Ryzenâ„¢ support PCIe 3.0 x16/x0, x8/x8 modes
- Ryzenâ„¢ with Radeonâ„¢ Vega Graphics and 2nd Gen AMD Ryzenâ„¢ with Radeonâ„¢ Graphics support PCIe 3.0 x8 mode
- 1x PCIe 4.0/ 3.0 x16 slot (PCI_E5, supports x4 mode)
- 2x PCIe 4.0/ 3.0 x1 slots
|
Multi-GPU |
- Supports 3-Way NVIDIA® SLI™ Technology
- Supports 3-Way AMDA® CrossFire™ Technology
|
Storage |
- 4x SATA 6Gb/s ports
- 2x M.2 slots (M2_2/ M2_3, Key M)
- Support PCIe 4.0/ 3.0 x4 and SATA 6Gb/s
- Support 2242/ 2260 /2280 storage devices
- 1x M.2 slot (M2_1, Key M)
- Supports PCIe 4.0 x4 (3rd Gen AMD Ryzenâ„¢)
- Supports PCIe 3.0 x4 (2nd Gen AMD Ryzenâ„¢/ Ryzenâ„¢ with Radeonâ„¢ Vega Graphics and 2nd Gen AMD Ryzenâ„¢ with Radeonâ„¢ Graphics)
- Supports 2242/ 2260 /2280/ 22110 storage devices
|
RAID |
Supports RAID 0, RAID 1 and RAID 10 |
USB |
- 3x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) ports (2 Type-A ports on the back panel, 1 Type-C internal connector)
- 4x USB 3.2 Gen1 (SuperSpeed USB) ports through the internal USB 3.2 Gen1 connectors
- 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)
- 2x USB 3.2 Gen2 (3rd Gen AMD Ryzenâ„¢) or USB 3.2 Gen1 (2nd Gen AMD Ryzenâ„¢/ Ryzenâ„¢ with Radeonâ„¢ Vega Graphics and 2nd Gen AMD Ryzenâ„¢ with Radeonâ„¢ Graphics) ports (1x Type-A & 1x Type-C) on the back panel
- 2x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
|
Audio |
- 1x Realtek® ALC1220 Codec
- 7.1-Channel High Definition Audio
- 1x Realtek® ALC4050H Codec
|
LAN |
1x Realtek® RTL8125 2.5 Gbps LAN controller |
WiFi & Bluetooth |
Intel® Wi-Fi 6 AX200
- Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
- Supports Bluetooth 5
- The Wireless module is pre-install in the M2_4 (Key-E) slot
|
Internal connectors |
- 1x 24-pin ATX main power connector
- 2x 8-pin ATX 12V power connectors
- 8x SATA 6Gb/s connectors
- 2x M.2 slots (M-Key)
- 1x USB 3.2 Gen2 Type-C port
- 2x USB 3.2 Gen1 connectors (supports additional 4 USB 3.2 Gen1 ports)
- 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1x 4-pin CPU fan connector
- 1x 4-pin Water Pump Fan connector
- 4x 4-pin system fan connectors
- 1x Front panel audio connector
- 2x System panel connectors
- 1x Chassis Intrusion connector
- 1x 4-pin 5050 RGB LED connector
- 2x 3-pin ARGB LED connectors
- 1x 3-pin CORSAIR LED connector
- 1x Slow mode booting jumper
- 1x Power button
- 1x Reset button
|
Back panel ports |
- 1x 24-pin ATX main power connector
- 2x 8-pin ATX 12V power connectors
- 4x SATA 6Gb/s connectors
- 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
- 2x USB 3.2 Gen 1 connectors (support additional 4 USB 3.2 Gen 1 ports)
- 1x USB 3.2 Gen 2 Type-C Port
- 1x 4-pin CPU fan connector
- 5x 4-pin system fan connectors
- 1x 4-pin water-pump connector
- 1x Front panel audio connector
|
Dimensions |
- 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
- ATX Form Factor
|
Operating System |
Support for Windows® 10 64-bit |
Mounting |
9 mounting holes |
Warranty |
3 Years |
Note |
***Features, Price and Specifications are subject to change without notice. |
